ARD文件打开方式

ARD文件打开方式

ARD import plugin v1.0 for Adobe Illustrator CSAI盒型插件ARD文件打开方式

ARD import plugin v1.0 for Adobe Illustrator CSAI盒型插件ARD文件打开方式Installation Requirements

Copy ArtiosCAD_WAI11r_free.aip to the plug-ins directory under Illustrator CS. Look for an Adobe\Adobe Illustrator CS\Plug-ins directory under one of your local hard drives.

将“artioscad_wai11r_free.aip”文件复制，拷贝到“Adobe Illustrator CS\Plug-ins”文件夹下

如果是增效工具的话就放到AI安装路径插件区里，X:\Program Files\Adobe\Adobe Illustrator CS3\增效工具

Features========* Dedicated alignment tools to position the structural data relative to the graphics* A timestamp is embedded in the illustrator file so that Illustrator can automatically update its CAD layer when the original CAD file is edited.

Known Issues and Limitations============================* Text, graphics, fills, strokes and dimensions are NOT read in* Bleed, Coating, Structure and annotation layers are read in. All other CAD layers are not read in.
